Zebra MC33 Series User Manual

Accessories
189
Replacement Hand Strap for MC33XX-R/S
To install the hand strap:
1. Thread the end of the hand strap with the tab through the slot toward the top of the MC33XX-R/S.
Figure 57 Thread Tab Through Top Slot
2. Slide the tab through the slit in the hand strap so that the tip of the tab is facing away from the MC33XX-R/S.
Figure 58 Slide Tab Through Slit
3. Thread the end of the hand strap with the velcro through the slot at the bottom of the MC33XX-R/S.

Zebra MC33 Series Specifications

General

Connectivity	USB 2.0, Bluetooth
Touch Panel	Capacitive, glove and wet touch support
Keypad Options	Touchscreen or physical keypad
Scanning	1D/2D barcode scanning
Wireless LAN	IEEE 802.11 a/b/g/n/ac
Operating Temperature	-20° C to 50° C
