Zebra MC33 Series User Manual

Specifications
206
Roll Condition: 20 mil Code 39 at 10 in.
± 35° from vertical
Pitch Angle Condition: 20 mil Code 39 at 10 in.
± 65° from normal
Skew Tolerance Condition: 20 mil Code 39 at 10 in.
± 40° from normal
Ambient Light Tolerant to typical artificial indoor and natural outdoor (direct
sunlight) lighting conditions.
Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED:
450 ft. Candles (4,844 Lux)
Sunlight: 10,000 Ft Candles (107,640 Lux)
Note: LED lighting with high AC ripple content can impact
scanning performance.
Scan Repetition Rate 104 (± 14) scans/sec (bidirectional)
Scan Angle Wide (Default): 47° (typical)
Medium: 35° (typical)
Narrow: 10° (typical)
2D Imager Engine (SE4750) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Focal Distance From front of engine: 17.7 cm (7.0 in.)
Laser Aiming Element Visible Laser Diode (VLD): 655 nm +/- 10 nm
Central Dot Optical Power: 0.6 mW (typical)
Pattern Angle: 48.0º horizontal, 38.0º vertical
Illumination System LEDs: Warm white LED
Pattern Angle: 80° at 505 intensity
2D Extended Range Imager Engine (SE4850) Specifications
Field of View Near camera: Horizontal - 32.0°, Vertical 20°
Far camera: Horizontal - 12°, Vertical - 7.6°
Image Resolution 1280 horizontal X 800 vertical pixels
Table 25 MC33XX Technical Specifications (Continued)
Item Description
