Accessories
116
4-Slot Spare Battery Charger
CAUTION: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines
on page 185.
The 4-Slot Spare Battery Charger:
• Charges up to 4 spare batteries.
• Provides 4.2 VDC power to charge the spare battery.
Setup
Figure 39 4-Slot Spare Battery Charger Setup
1 Power supply
2 AC line cord
3 DC line cord
4 Spare battery charging LED
5 Charging slot
1
2
4
3
5
