Connecting the USB Charge/Com Snap-on Cup Cable to Host Computer
To connect the USB Charge/Com Snap-on Cup cable to a host computer:
1. Connect the USB Charge/Com Snap-on Cup to the device.
2. Connect the USB connector to a host computer.
Figure 45 Connecting USB Charge/Com Snap-on Cup to Host Computer
1 Host computer
2 USB cable
3 USB charge/com snap-on cup
1
2
3
