Data Capture
75
Figure 20 DS3608/DS3678 Pick List Mode with Multiple Barcodes in Aiming Pattern
5. The captured data appears in the text field.
Pairing the RS507/RS507X/RS6000 Hands-Free Imager
To connect the RS507/RS507X or RS6000 imager to the device, use one of the following methods:
• Near Field Communication (NFC) (RS6000 only)
• Simple Serial Interface (SSI)
• Bluetooth Human Interface Device (HID) Mode.
Pairing Using Near Field Communication
NOTE: NFC is supported on the premium configurations of the device.
The MC93XX provides the ability to pair the RS6000 using NFC.
1. Ensure that NFC is enabled on the MC93XX.
2. Align the NFC icon on the RS6000 with the NFC icon on the back of the MC93XX.
The Status LED blinks blue indicating that the RS6000 is attempting to establish connection with the
MC93XX. When connection is established, the Status LED turns off and the RS6000 emits a single
string of low/high beeps.
A notification appears on the MC93XX screen.
The icon appears in the Status bar.
