Keypads
165
53-Keys IBM-5250 Emulator Keypad
The IBM-5250 emulator keypad contains a Power button, application keys, scroll keys and a function key.
The keypad is color-coded to indicate the alternate function key (blue) values. Note that keypad functions
can be changed by an application so the device’s keypad may not function exactly as described. See the
Key Descriptions table for key and button details, and the Keypad Special Functions table for the keypad’s
various functions.
Figure 59 53-Keys IBM-5250 Emulator Keypad
NOTE: The IBM-5250 emulator configuration is only used when the device is running the 5250 emulation
software.
Table 13 IBM-5250 Emulator Descriptions
Key Description
Power (red) Turns the device on and off.
Performs a warm boot and a hard reset. See Resetting the Device for more
information.
P1/P2 User programmable keys:
• By default, P1 is the dedicated PTT key.
• By default, P2 acts like another Scan key.
Scan (yellow) Activates the scanner/imager in a scan enabled application.
