Keypads
180
29-Keys Shifted Alpha Keypad
The 29-key keypad contains a Power button, application keys, scroll keys and a function key. Note that
keypad functions can be changed by an application so the MC93XX’s keypad may not function exactly as
described. See the Key Descriptions table for key and button details, and the Keypad Special Functions
table for the keypad’s various functions.
Figure 64 29-Keys Keypad
Table 18 29-Keys Descriptions
Key Description
Power (red) Turns the device on and off.
Performs a warm boot and a hard reset. See Resetting the Device for more
information.
P1/P2 User programmable keys:
• By default, P1 is the dedicated PTT key.
• By default, P2 acts like another Scan key.
Scan (yellow) Activates the scanner/imager in a scan enabled application.
Up and Down Moves up and down from one item to another.
