Accessories
139
4.
Hang the bracket on the screws.
5. Install two top screws.
6. Tighten all screws.
7. Assemble the four 4-Slot Battery Chargers or cradle onto the bracket. See steps 7 through 11 in 4-Slot
Charge Only ShareCradle Rack Installation on page 132.
8. Route cables and connect to power source.
CAUTION: Installer should ensure that all building codes are followed when connecting the power supplies
to an AC power source.
While installing the brackets, power supplies and cables:
• Use tie wraps to secure cables to the bracket and rails.
• Coil cables wherever possible.
• Route power cables along the rails.
• Route inter-cradle cables to the side rails and then from the rails to the bracket.
