Zebra MC93 Series - Page 157

Keypads
157
9.
Using a Torx T8 screwdriver with a large grip and a long shaft, secure the keypad to the device using
the two screws. Torque screws to 5.8 kgf-cm or 5.0 lbf-in.
10. Turn the device over so that the keypad latches are visible.
11. Slide both the keypad latches toward the top of the device.
1 Keypad screws
1 Keypad latches
1
1
