Zebra MC93 Series - 16-Slot Spare Battery Charger

Getting Started
20
3.
Using a Torx T8 screwdriver with a large grip, remove the two keypad latch screws from inside the
battery slot.
4. Slide the keypad latches toward the bottom of the device.
NOTE: If the keypad latches are hard to move, use a screwdriver to gently slide them towards the bottom
of the device.
5. Turn the device over so that the keypad is visible.
1 Keypad latch screws
1 Screwdriver
Keypad latches
1
2
1
