6 - 12 TC8000 User Guide
5-Slot Ethernet Cradle
The 5-Slot Ethernet Cradle:
•
Provides 5 VDC (nominal) power for operating the TC8000.
•
Connects up to five TC8000s to an Ethernet network.
•
Simultaneously charges up to five TC8000s.
Figure 6-7 5-Slot Ethernet Cradle (shown on optional Desk Mount)
Charging the TC8000
To charge the TC8000:
1. Insert the TC8000 in a charge well to begin charging.
NOTE
Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 7-1.
