6 - 24 TC8000 User Guide
3.5 mm Audio Adapter
The 3.5 mm Audio Adapter snaps onto the top of the TC8000 and removes easily when not in use. When attached
to the TC8000, the Audio Adapter allows a user to connect a wired 3.5 mm headset to the TC8000.
Attaching the Audio Adapter
1. Align the tabs on the Audio Adapter with the slots on the device.
2. Rotate the Adapter toward the back of the device until the Adapter snaps onto the device.
Figure 6-17 Attach Cable to TC8000
Connecting the Adapter to a Headset
Figure 6-18 3.5 mm Audio Adapter Connection
Removing the Audio Adapter
To remove the Audio Adapter:
1. Press the release level toward the cable.
2. Rotate the adapter toward the front of the device and remove.
