1 - 12 TC8000 User Guide
Figure 1-14 Slide Tab onto Clip
Hot Swap Mode
The TC8000 provides a Hot Swap mode where the user can replace the battery without powering off the device.
When the user removes the battery, the display turns off and the Charging/Scan LED lights red for approximately
seven seconds to indicate Hot Swap mode.
In Hot Swap mode, the TC8000 stays connected to the Wi-Fi network for 30 seconds. Replace the battery within 30
seconds to preserve the active Wi-Fi session. After 30 seconds, the TC8000 establishes a new Wi-Fi connection.
After 30 seconds the TC8000 enters Standby mode. In Standby mode RAM is preserved for 20 minutes. If the user
does not install a charged battery within 20 minutes, data in RAM will be lost.
Replacing the Battery
To remove the battery:
1. Press the two battery release latches in.
CAUTION
Do not press the trigger while removing the battery.
