6 - 22 TC8000 User Guide
Quick Disconnect Audio Adapter
The Quick Disconnect Audio Adapter snaps onto the top of the TC8000 and removes easily when not in use. When
attached to the TC8000, the Quick Disconnect Audio Adapter allows a user to connect a wired headset to the
TC8000.
Attaching the Audio Adapter
1. Align the tabs on the Audio Adapter with the slots on the device.
2. Rotate the Adapter toward the back of the device until the Adapter snaps onto the device.
Figure 6-15 Attach Cable to TC8000
Connecting the Adapter to a Headset
Figure 6-16 Quick Disconnect Audio Adapter Connection to Headset
