Data Capture 3 - 7

Bar Code Capture with RS507 Hands-Free Imager

Pair the RS507 with the TC8000. See Pairing the RS507 Hands-Free Imager Using SSI on page 3-8 or Pairing the

RS507 Hands-Free Imager Using Bluetooth HID on page 3-9 for more information.

1. Ensure that an application is open on the device and a text field is in focus (text cursor in text field).

2. Point the RS507 at a bar code.

Figure 3-8 Bar Code Scanning with RS507

3. Press and hold the trigger.

The red laser aiming pattern turns on to assist in aiming. Ensure the bar code is within the area formed by the

cross-hairs in the aiming pattern. The aiming dot is used for increased visibility in bright lighting conditions.

The RS507 LEDs light green, a beep sounds to indicate the bar code was decoded successfully. Note that

when the RS507 is in Pick List Mode, the RS507 does not decode the bar code until the center of the crosshair

touches the bar code.

Figure 3-9 Aiming Pattern
