Data Capture 3 - 5
3. Press the trigger button.
Figure 3-4 Imager Scanning
4. Ensure the red scan beam covers the entire bar code. The Charging/Scan LED Indicators illuminate green and
a beep sounds to indicate a successful decode.
Figure 3-5 Imager Aiming Pattern
Figure 3-6 Imager Pick List Mode with Multiple Bar Codes
