Zebra VC80 User Manual

Specifications A - 3
Integrated
Sensors
Motion (accelerometer); temperature; ignition
Shock/Vibration
IEC 60721-3-5M3; MIL-STD 810G; Method 514.6; MIL-STD 810G; Method 516.6
Power
Consumption
• 16W: Display brightness at 1/2, keyboard backlight off, radio in received mode,
UPS battery fully charged.
• 38W: Full display brightness, full external keyboard backlight on, radio running ping
test, UPS battery is charging, scanner connected.
• 84W: Full display brightness, full external keyboard backlight on, radio running ping
test, UPS battery is charging, scanner connected, touch screen heater on.
Performance Characteristics
CPU/RAM Intel E3825 Dual Core, 1.33 GHz with 2GB RAM or
Intel E3845 Quad Core, 1.91 GHz with 4GB RAM
Operating
System
• Windows Embedded Standard 7, 64 bit; Windows 7 Professional, 64 bit
• Windows 10 IoT Enterprise 2016 LTSB Entry
Internal
Expansion
Two PCIe mini slots (one standard, one optional); one M.2 slot
Mass Storage
mSATA SSD: 32 or 64 GB
Additional
Software
My-T-Soft configurable on-screen keyboard; Scanner Wedge with code manipula-
tions; Tekterm
Application
Development
Standard Windows plus WMI additions
Touchscreen • Resistive touchscreen with passive stylus or finger operation
• Freezer version includes integrated touchscreen heater for evaporates external
condensation.
• Construction: Film-Glass (FG)
• Hardness of surface: 3H (ASTM D3363)
• Resistance: 35 million actuations
Audio
High volume 87 dBA speaker (at 1 foot distance)
Push-to-Talk
External optional speaker/microphone
WLAN Wireless Data Communications
WLAN radio IEEE 802.11a/b/g/n/ac 2x2 MIMO
Table A-1 Technical Specifications (Continued)
Item Description

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
