Zebra VC80 User Manual

A - 4 VC80 User Guide
Output Power 2.4GHz=+17.5dBm max, 5GHz=+17.5dBm max
Data Rate 867Mbps @ 5GHz, 300Mbps @ 2.5GHz
Frequency
Range
Country dependent
2.4GHz band (802.11b/g/n) = 2400-2483.5MHz
5GHz band (802.11a/n/ac) = 5150-5350MHz, 5470-5855MHz.
Antenna Internal or external
WLAN Security WPA, WPA2, AES, TKIP, WEP, 802.11x, CCX v4
WPAN Wireless Data Communications
Bluetooth Bluetooth V2.1 + EDR (Window7/10)
Bluetooth V4.0 Smart Ready (Windows 10)
GPS
GPS Optional with DGPS support
Power Supply
Power Supply Internal power supply 12-48V nominal
Table A-1 Technical Specifications (Continued)
Item Description

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
