Zebra VC80 User Manual

3 - 12 VC80 User Guide
Click Mode
• Interactive Touch - Shows the current click mode emulation for a single touch. The setting is only
active if the driver is responsible for the pointer handling via the standard mouse interface into the OS.
• Extended Touch - Vista and above, UPDD can deliver touch co-ordinate data to the Windows OS via
three interfaces: mouse class, HID class, Win8TI API interface.
• Visual Notification - Indicates if visual feedback is shown during Interactive Touch right click
countdown.
• Interactive Switch Delay - Select the delay pace.
• Sound Options - Configure touch sound options.
• System Mouse Settings - Adjust the mouse pointer settings defined within the OS.
• Test Icons - Test Right Click and Double Click. A tick is shown if the click test is successful.
Figure 3-12 Click Mode Settings (VC80 with Windows 7)

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
