‘NEXT’.
Press ‘SET’.
X Y Z
MOVE ZMOVE X Y
BACK SET
Before starting the CNC milling process the machine must be calibrated to the mounted material on the
worktable. Skipping the calibration process may result in damaging the milling cutter, machine or the tool-
head and after that hurting the user.
Enter the ‘SETTINGS’ section. Turn ‘ON’ your Spindle. Go to the ‘CALIBRATE’ section.
NOTE
The movement in the X and Y axes will be disabled until they are homed. It is a safety procedure, to
protect the machine against damage.
The movement in the Z axis is avaliable all the time. Use it to move the milling cutter above the
surface height of the prepared material
CNC milling workow
CANCEL NEXT
EXTERNAL
INTERNAL
example.gcode
PAUSE
ABORTSETTINGS
SPINDLE
JOB SPEED
ON OFF
BACK
CALIBRATE SETTINGSCHOOSE
FILE
STARTBACK
example.gcode
progress 20% 0h34m elapsed

  
