Product Manual - ZMORPH FAB back to table of content >>
152
15.4 Material application
Prepare the Thick Paste
Extruder.
Unlock the syringe blockade. Pull the piston out from
the syringe.
Manually move the piston
to the starting position.
Fill the syringe with the
prepared material.
Push the piston inside
the syringe and lock the
syringe blockade.
Put the Thick Paste toolhead
on the X-cariage mount.
Screw tight the front
screw.
Connect the ‘LEFT’ connector
to the Left socket on the
machine frame.
Thick paste extruding workow

Zmorph FAB Specifications

General

Build Volume	250 x 235 x 165 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Print Speed	up to 100 mm/s
Software	Voxelizer
Dimensions	530 x 555 x 480 mm
Layer Resolution	0.05 - 0.3 mm
Connectivity	USB, Ethernet
Supported Materials	PLA, ABS, PETG, TPU, Nylon
Power Supply	24V DC
Print Technology	Fused Filament Fabrication (FFF)
Extruder Type	Single Extruder
Display	5-inch capacitive touchscreen
