Pioneer Gold 3.00 Controller Technical Guide
WIRING
Important Wiring Considerations
Important Wiring Considerations
Please carefully read and apply the following information when
wiring the Pioneer Gold Controller and the Electric Heat Board.
1. All wiring is to be in accordance with local and
2. All 24 VAC wiring must be connected so that all
ground wires remain common. Failure to follow this
procedure can result in damage to the controller and
connected devices.
3. Minimum wire size for 24 VAC wiring should be
18-gauge
4. Minimum wire size for all sensors should be 24-gauge.
Some sensors require two-conductor wire and some
require three-or four-conductor wire.
5. Minimum wire size for 24 VAC thermostat wiring
should be 22 gauge.
6. Be sure that all wiring connections are properly
inserted and tightened into the terminal blocks. Do
not allow wire strands to stick out and touch adjoining
terminals which could potentially cause a short circuit.
7. When communication wiring is to be used to
connect to other communication devices, all wiring
must be plenum-rated, minimum 18-gauge, two-
conductor, twisted-pair with shield. AAON can supply
is color coded for the network or local loop. Please
consult your AAON distributor for information. If
desired, Belden #82760 or equivalent wire may also
be used.
8. Before applying power to the Pioneer Gold Controller,
be sure to recheck all wiring connections and
terminations thoroughly.
Powering Up
up, the POWER LEDs should light up and stay on continuously.
If they do not light up, check to be sure that you have 24 VAC
connected to the controller and expansion module, that the wiring
connections are tight, and that they are wired for the correct
polarity. The 24 VAC power must be connected so that all ground
wires remain common. If after making all these checks, the
POWER LEDs do not light up, please contact AAON Technical
Support for assistance.
