AAON ASM02780 - Figure 1-8: H10 WSHP Harness Wiring; Figure 1-9: H13 Standard Input Harness Wiring

1-9
Pioneer Gold 3.00 Controller Technical Guide
WIRING
Harness Wiring
Figure 1-8: H10 WSHP Harness Wiring
Figure 1-9: H13 Standard Input Harness Wiring
RUN/STOP SIGNAL (15)
BLK
RED
BLU
WHT
24 VAC OUTPUT (12)
GROUND (3)
PWM (10)
24V
R
GND
PWM
CT-5
16
8
15
7
14
6
13
5
12
4
11
3
10
2
9
1
NOTE:
represented by a dotted line.
Multicolored wires are
GROUND (7)
24 VAC INPUT (14)
HIGH PRESSURE SWITCH (6)
24 VAC (13)
LOW PRESSURE SWITCH (5)
GROUND (12)
GROUND (11)
GROUND (9)
GROUND (8)
GROUND (10)
LIQUID LINE TEMP (3)
EVAP COIL TEMP (2)
WATER FLOW SWITCH (1)
COND OVERFLOW 1 (4)
7 14
6 13
5 12
4 11
3 10
2 9
1 8
CT-6
GND
R
HPS
24V
LPS
GND
OVF1
GND
LLT
GND
ECT
GND
WFS
E
BLU
RED
BLK
YEL
GRN
ORN
BRN
PNK
TAN
GRA
PUR
WHT
BLU/BLK
GRN/BLK
