Pioneer Gold 3.00 Controller Technical Guide
BACnet
®
MS/TP and IP Binary Inputs
BACnet
®
Point #
BACnet
®
Point Name
BACnet
®
Description
BI: 1  Status of the G input terminal
BI: 2  
BI: 3  
BI: 4  Status of the O input terminal
BI: 5  
BI: 6  Status of the DH input terminal
BI: 7 Night Setback Enable Status of the night setback enable input terminal
BI: 8 Night Setback Override Status of the night setback override input terminal
BI: 9 Night Setback Tstat Status of the night setback thermostat input terminal
BI: 10 Emergency Shutdown Status Status of the emergency shutdown input terminal
BI: 11 Waterside Economizer Status of the waterside economizer relay output
BI: 12  
BI: 13  
BI: 14  
BI: 15 Supply Fan Low Speed Status of the low speed supply fan relay output
BI: 16 Supply Fan High Speed Status of the high speed supply fan relay output
BI: 17 Electric Heat Status of the electric heat relay output
BI: 18 Reversing Valve Status of the reversing valve relay output
BI: 19  Status of the water valve or pump relay output
BI: 20 HGRH Status of the hot gas reheat relay output
BI: 21  Status of the alarm relay output and indicates if any alarm is present
BI: 22 Occupancy Status Indication of space occupancy
BI: 23  
BI: 24 Water Economizer Failed Indicates if waterside economizer has failed to meet cooling setpoint within allotted time
BI: 25  
BI: 26  
BI: 27  
BI: 28  
BI: 29  
BI: 30  
BI: 31  
BI: 32  
BI: 33  
BI: 34  
BI: 35  
BI: 36 Occupancy Sensor Status of occupancy sensor which will force the unit into occupancy
BI: 37  
BI: 38  
BI: 39  
BI: 40 󰀨 󰀨
Table 1-17: BACnet
®
MS/TP and IP Parameter Binary Inputs
BACnet
®
MS/TP AND IP PARAMETERS
BACnet
®
MS/TP and IP Binary Inputs
