2-22
Pioneer Gold 3.00 Controller Technical Guide
ALARMS
Viewing Alarms
Alarm Status
From the Main Screen, press the <Alarms> icon. The Alarms 1
Screen will appear. See Figures 2-20, this page. There are three
Alarms Screens. Press the <Next> button to access each screen.
Press the <Back> button to access the previous screen. Press the
<Menu> button to return to the Main Screen.
The status for each alarm should be Ready or Normal. If there
is an alarm, the word Alarm will appear in red. The abbreviation
L.O. in red stands for “Locked Out”. This means that there is
currently one or more alarms active, and any item that shows
by the particular alarm. Continue scrolling through the Alarms
pages until you see the item that shows “Alarm” to identify
which item is in an alarm state that is causing associated items
to be Locked Out.
Figure 2-20: Alarms Screens
Alarms 1
Supply Fan:
Compressor:
Water Economizer:
Water Heat:
Electric Heat:
Water Valve:
Desuperheater:
Economizer Failed:
Menu
Ready
Ready
Ready
Ready
Ready
Ready
Ready
Normal
Next
Alarms 2
Low Voltage Alarm:
High Voltage Alarm:
Water Leaving Temp:
Water Entering Temp:
Liquid Line Temp:
Evap Coil Temp:
High Pressure Alarm:
Low Suction Alarm:
Back
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Next
Alarms 3
Emergency Shutdown:
Auxiliary Input Alarm:
DI1 Comp Interlock:
DI2 Comp Interlock:
Space Sensor Alarm:
CO2 Alarm
Condensate Overflow:
High SAT Cutoff:
Back
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Normal
