AAON ASM02780 User Manual

3-10
Pioneer Gold 3.00 Controller Technical Guide
NOTE: Trend Logging requires Prism 2 v.5.02 or higher.
PIONEER GOLD CONTROLLER TREND LOGS
Log
Abbreviation
(Unit)
Item Description
Enumerated
Values or
Bits*
Mode HVAC mode See Table 3-2.
Occ Occupancy status See Table 3-2
Space Space Temperature
SpcRH Space Relative Humidity
SpClSp Space Temp Cooling Setpoint
SpHtSp Space Temp Heating Setpoint
SAT Supply Air Temperature
SATSP Supply Air Temp Setpoint
EvapCoil Evap Coil Temperature
SuctPres Suction Pressure
DisPres Discharge Pressure
EntWtr Entering Water Temperature
RefLqLn Refrigerant Liquid Line Temp
LvgWtr Leaving Water Temp
EntHtWtr Entering Hot Water Temp
CO2 Space CO
2
Level
WtrFlw Water Flow Rate
CtrlVolt Control Supply Voltage
Fan Supply Fan Speed
Pump Pump Speed
DmprOvr Damper Position
HtWtrVlv Hot Water Valve Position
HGRHVlv Hot Gas Reheat Valve
Position
Alarm1 Alarms Group 1 See Table 3-3.
Alarm2 Alarms Group 2 See Table 3-3.
BinOut Binary Outputs See Table 3-3.
BinIn Binary Inputs See Table 3-3.
Tstat T-STAT Inputs See Table 3-3.
RSV1 Reserved
RSV2 Reserved
RSV3 Reserved
RSV4 Reserved
RSV5 Reserved
RSV6 Reserved
RSV7 Reserved
RSV8 Reserved
RSV9 Reserved
RSV10 Reserved
TREND LOG ENUMERATED VALUES
Item Description Value Description
Occupancy
Status
0 Unoccupied
1 Occupied
HVAC
Mode
0 O󰀨
1 Vent
2 Cool
3 Heat
4 Dehum
Table 3-1: Pioneer Gold Controller Trend Logs
Table 3-2: Trend Log Enumerated Values
TREND LOGS
Pioneer Gold 3.0 Controller Trend Logs
