Pioneer Gold 3.00 Controller Technical Guide
WIRING
Pioneer Gold Controller and Electric Heat Board Input/Output Maps
PIONEER GOLD CONTROLLER
DIGITAL INPUTS
G
Y1
Y2
O
DH
W1
NSB
NSB OVR
ESD Emergency Shutdown
NSB TH
COF
COF2
AUX
HPS High Pressure Switch
LPS Low Pressure Switch
DI1
DI2
* Not a Fire/Life Safety Device
ANALOG INPUTS
SPT Suction Pressure
DPT Discharge Pressure
EWT Entering Water Temperature
LLT Liquid Line Temperature
ECT
HWT Not Used
SAT
SPAT Space Temperature
CO2
TOUCHSCREEN INPUTS
SPAT Space Temperature
SPAH Space Humidity
UNIVERSAL INPUTS
UI1 LWT - Leaving Water Temperature
UI2 Spare
UI3 Spare
UI4 Spare
Input/Output Map
See Table 1-4 through 1-7, this page for Pioneer Gold Controller
Inputs/Outputs. Future items are grayed out.
Table 1-4: Pioneer Gold Inputs
DIGITAL OUTPUTS (24 VAC)
R/C
ALM
ALM1/ALM2
Fan/Fan Supply Fan Enable
Fan2/Fan
Y1/Y1
Y2/Y2
Y3/Y3 Not Used
RV/RV Reversing Valve
W1/W
MV/MV
HG/HG HGRH Valve
WSE/WSE WSE Valve
DO1
ANALOG OUTPUTS (0-10 VDC)
SFS Supply Fan Speed
PUMP Not Used
MWV Not Used
DMPR OVR
Damper Override
AO1 Spare
AO2 Spare
ELECTRIC HEAT BOARD INPUTS
LIMIT Limit (Hi) Switch
ELECTRIC HEAT BOARD OUTPUTS
Heat 1
Heat 2
COMMUNICATION TERMINALS
R/C Extra Power Terminals
BACnet
®
Terminal (Selectable)
T-STAT
Pioneer Gold Touchscreen
3 MODBUS
Ports
Ethernet Port
Table 1-5: Pioneer Gold Outputs
Table 1-6: Pioneer Gold Communication Terminals
Table 1-7: Pioneer Gold Electric Heat Board
Inputs and Outputs
