AAON ASM02780 User Manual

1-10
Pioneer Gold 3.00 Controller Technical Guide
WIRING
Pioneer Gold Electric Heat Board Components and Wiring
Figure 1-10: Pioneer Gold Electric Heat Board Components and Wiring
A-
S
B+
SW1
HEAT1
HEAT2
POWER
STATUS
J4
J6
A-
S
B+
J1
J3
J2
J7
J5
S
A-
J5
B+
Heat Relay 1
Heat Relay 2
18-30 VACGND
Line Voltage
Size transformer for correct total load.
Electric Heat Expansion Module = 20 VA
G007090
Harness WV Electric Heat
A-
S
B+
Pioneer Gold Controller
MODBUS Expansion Terminal
Typical terminal blocks. All
wiring to be S (G) to S (G),
A- to A-, and B+ to B+
MODBUSMODBUS
MODBUS
