1-1
Pioneer Gold 3.00 Controller Technical Guide
OVERVIEW
Pioneer Gold System Overview
Applications
The AAON
®
Pioneer Gold 3.00 Controller with Touchscreen
interface, BACnet
®
MS/TP, BACnet
®
IP, and MODBUS RTU
communication protocols is designed for AAON
®
horizontal and
vertical water-source heat pump units—WH and WV series. All
of the energy saving features and options available on AAON
®
WH and WV Series water-source heat pumps can be controlled
with the Pioneer Gold Controller.
The Water-Source Heat Pump (WSHP) Pioneer Gold Controller
contains all the functionality required to operate basic and
®
WH and WV Series WSHP
units. The controller can operate with a standard heat pump room
thermostat (by others) or can operate as a Stand-Alone system
with the Pioneer Gold Touchscreen Space and Humidity Sensor
or Simple Space Temperature Sensor.
The controller also contains a terminal block for communication
to the Pioneer Gold Electric Heat Board for additional heat stages.
NOTE: If the application currently uses an obsolete
mercury bulb type thermostat, it must be upgraded
to an electronic thermostat. The unit will not
function properly when controlled via a mercury
bulb thermostat.
The controller has outputs to control a supply fan, compressor, and
reversing valve. It also provides I/O for additional functionality.
The Pioneer Gold is used for Constant Volume applications.
PIONEER GOLD FEATURES AND OPTIONS
UNIT
CAPACITY
CONTROL
ADVANCED
ALARMS
•
•
USER
INTERFACE
with Two Levels of Security
SERVICE AND
RELIABILITY
FEATURES
• Firmware Update via USB Port
• Fault and Status Indicator LED
•
•
Reset)
•
•
STAND-ALONE
CAPABILITY
Thermostat Terminals
NETWORKING
CAPABILITY
®
®
IP
MODBUS RTU
ADVANCED
FEATURES
• Waterside Economizer Operation
•
•
•
•
•
•
•
•
•
•
•
®
•
•
•
Interface
•
•
Space Temperature and Humidity Sensor
(Optional)
BASIC
FEATURES
•
• Random Start Delay
•
•
• High Refrigerant Pressure Protection
•
• Reversing Valve Default to Heating Mode
•
• Emergency Shutdown Input (not to be used as a
• Night Setback Mode
• Night Setback Override Thermostat Input
•
•
•
• Occupancy Scheduling
• Seven-Day, Two-Event-Per-Day Scheduling
BASIC
ALARMS
•
•
•
Table 1-1: Pioneer Gold - Features and Options
