Pioneer Gold 3.00 Controller Technical Guide
SETPOINTS
Values
Setpoint Values
Refer to the following for setpoint names and their min/max
and defaults.
Cooling Setpoints
• Occupied Cooling: Sets the Cooling Setpoint. Default:
• Unoccupied Cooling: Sets the Unoccupied Cooling
• Cooling Enable Deadband: How far away from
Range: 1-5°F
• Supply Air Cooling Setpoint:
Range: 45-65°F
Heating Setpoints
• Occupied Heating: Sets the Heating Setpoint.
• Unoccupied Heating: Sets the Unoccupied Heating
• Heating Enable Deadband: How far away from the
Range: 1-5°F
• Supply Air Heating Setpoint:
Range: 55-120°F
• Auxiliary Heat Deadband: Space Temp has to be this
far below setpoint before Aux Heat can energize.
Dehumidication Setpoints
• Dehumidification Enable: If Space RH is above
• Dehumidication Lockout: If the Space Temp is below
• Supply Air Reheat Setpoint: In the Modulating Reheat
mode, the controller will try to maintain this setpoint.
Economizer Setpoints
• Economizer Cooling Enable: If the Entering Water
Temperature is below this value, the Economizer can be
• Economizer Heating Enable: If the Entering Water
Temperature is Above this value, the Economizer can be
• Water Econ Cooling Failure Time and
Water Econ Heating Failure Time
If the Waterside Economizer is enabled for cooling
or heating, the failure time is the time period before
it switches to Compressor Cool or Heat. Setting the
value to 255 will disable the timer so the Waterside
Compressor Setpoints
• Minimum On Time: Compressor must run for this amount
Range: 120-255 seconds
• Minimum O Time: Compressor must remain for this
amount of time before it can turn on. Default: 120
• Interstage On Delay: If Stage 1 is energized, the
controller must wait for this amount of time before
255 seconds
• Interstage O Delay: If Stage 2 is energized, the
controller must wait for this amount of time before
255 seconds
Supply Fan Setpoints
• Supply Fan Minimum Speed: This is the Low Fan
Range: 20-100%
• Supply Fan Maximum Speed: This is the High Fan
Range: 20-100%
CO2 Setpoints
• CO2 Override: If CO is above this value, the OA
Range: 500-1500ppm
Glycol Percentage
This is the percentage of Glycol mixed in the loop water.
Range: 0-40%
