Pioneer Gold 3.00 Controller Technical Guide
SETUP GUIDE
Conguration
Compressor Control (Factory Set)
Select the type of compressor control you are using. Select one
option, and then press <OK> to save.
• Single ON/OFF: This option is only for a single speed
• 2 Step: This option is only for a single Two-Speed
Compressor (uses Unloader technology)
Waterside Economizer (WSE) (Field Set)
Select the type of Waterside Economizer (WSE) control you are
using. Select one option, and then press <OK> to save.
• OFF: Default. No Economizer. No Condenser Water
Loop function.
• COOL: WSE Valve cycles on based on Cooling Entering
Water Temperature Setpoints.
• HEAT: WSE Valve cycles on based on Heating Entering
Water Temperature Setpoints.
• COOL/HEAT: Dual. WSE Valve cycles on based on
Entering Water Temperature Setpoints of corresponding
mode demand.
Electric Heat Control (Field Wired)
Select the type of electric heat control you are using. Select one
option, and then press <OK> to save.
• OFF: The W1 additional Heat Stage will not be used
for external duct heat.
• Auxiliary Heat: The W1 heat output will be used as
a supplemental stage of heating to the compressors.
Duct Mounted Electric Aux Heat. Used to augment
Compressor Heat
• Emergency Heat: The W1 heat output will be enabled
when compressor heating is locked out and there is a
demand for heating. There is no supply air control. Duct
mounted Electric Emergency Heat. Used to replace
Compressor Heat.
Dehumidication
one option.
• OFF:
• Fan Speed Dehum: Runs compressor at full capacity
Unit must be equipped with a two-speed fan to use
this feature.
• Hot Gas Reheat: Reheat will operate Cooling,
Heating, and Economizer modes as a priority over
<OK> to save.
• Dehum Priority:
priority over Cooling, Heating, and Economizer modes.
• Full Reheat: For use when a Hot Gas Reheat coil is
present in the unit. This closes the water valve while
units in which the reheat coil is piped in series with
the coaxial heat exchanger. Not for use in very early
production units designed with the piping in parallel.
• Parallel Reheat Piping: This option applies only to
very early production units ordered with Hot Gas
Reheat, in which the reheat coil was piped in parallel
with the coaxial heat exchanger.
Desuperheater Control
Select the Desuperheater control. Check the box to have
Press <OK> to save.
• Desuperheater On: Check this box if using a
Desuperheater Control Valve. Desuperheater uses
Hot Leaving Water from the unit to heat domestic hot
water tank.
Water Flow Sensor for Desuperheater
Select the type of water flow sensor you are using for
Desuperheater. The AAON part number will be printed on the
sensor or wiring diagram. Select one option, and then press
<OK> to save.
• No Sensor
• V97450
• V97460
• V97470
• V97480
Compressor Interlock Inputs
Compressor operation will disable when selected inputs open.
Press <OK> to save.
• DI1 Comp Interlock
• DI2 Comp Interlock
Trendlog Rate
An internal Trend Log is constantly updated at a rate equal to
