Fieldbus control
153
Table 8 Pack Status Bits (Actual Signal 03.15)
Bit Name Description
0 WEB LOSS DETECTED A web loss has been detected. See chapter Actual signals
and parameters, parameters 60.03 and 60.04.
1 AT CORE DIAMETER The calculated diameter equals the core diameter. See
chapter Actual signals and parameters, parameter 65.01.
2 AT FULL DIAMETER The calculated diameter equals the max roll diameter. See
chapter Actual signals and parameters, parameter 65.02.
3 Reserved
4 Reserved
5 DANCER/TENSION CTRL
ON
The drive is running and the PI regulator is controlling web
tension. See chapter Actual signals and parameters,
parameters 62.09 and 63.09.
6 WEB2 SELECTED Web 2 has been selected and the corresponding gain, I-
Time and web dimensions are being used. See chapter
Actual signals and parameters, groups 62 DANCER
CONTROLS and 63 TENSION CONTROLS.
7 DANCER/TENSION
STALL ON
The web tension control is using the stall setpoints. See
chapter Actual signals and parameters, groups 62
DANCER CONTROLS and 63 TENSION CONTROLS.
8 TORQUE MODE ON - NO
TRIM
The drive is operating in open loop torque mode. See
chapter Actual signals and parameters, parameters 63.15
and 63.16.
9 TORQUE MEMORY ON The drive is reading the current torque value and storing it.
See chapter Actual signals and parameters, parameters
66.01 and 66.02.
10 TORQUE BOOST ON The drive is using the memorized torque value x the torque
boost. See chapter Actual signals and parameters,
parameters 66.03…66.05.
11 DIAMETER > LIMIT 1 The calculated diameter is greater than the user defined
limit. See chapter Actual signals and parameters,
parameter 65.16.
12 DIAMETER > LIMIT 2 The calculated diameter is greater than the user defined
limit. See chapter Actual signals and parameters
,
parameter 65.17.
13 DIAMETER < LIMIT 1 The calculated diameter is less than the user defined limit.
See chapter Actual signals and parameters, parameter
65.18.
14 DIAMETER < LIMIT 2 The calculated diameter is less than the user defined limit.
See chapter Actual signals and parameters, parameter
65.19.
15 Reserved
