ABB ACS880-107

DescriptionCode
Seismic designC180
Direct-on-line module cooling fansC188
Modules in their own compartmentsC204
Marine product certification issued by DNV GLC205
Marine product certification issued by the American Bureau of Shipping (ABS)C206
Marine product certification issued by Lloyd's Register (LR)C207
Marine product certification issued by Bureau VeritasC209
Marine product certification issued by China Classification Society (CCS)C228
Marine product certification issued by Russian Maritime Register of Shipping (RS)C229
d u /d t filteringE205
Sine output filterE206
Common mode filteringE208
EMC/RFI filter for 2nd environment TN (grounded) or IT (ungrounded) system, category C3E210
High speed filter unit (40 µH, 1500 A) in a 500 mm wide cubicleE230
High speed filter unit (20 µH, 2100 A) in a 500 mm wide cubicleE231
High speed filter unit (20 + 20 µH, 2100 A) in a 700 mm wide cubicle2E231
Service switch at inverter outputF267
Output contactorsF269
Output grounding switchF270
Output grounding terminalsF271
DC switch-disconnectorF286
DC fusesF287
DC fuse-disconnector(s)F288
Cabinet and module heating elements (external supply)G300
Cabinet lightingG301
Control (auxiliary) voltage 115 V ACG304
Terminals for connecting external control voltage (230 V AC or 115 V AC, eg. UPS)G307
Output for motor space heater (external supply)G313
Aluminum busbarsG314
Tin-plated copper DC busbarsG315
Control (auxiliary) voltage 230 V ACG320
Halogen-free wiring and materialsG330
Wire marking class A1G338
Wire marking class A2G339
Wire marking class A3G340
Wire marking class B1G341
Wire marking class C1G342
Corrosion indicatorG343
Auxiliary voltage transformerG344
Light-duty aluminum DC busbarsG412
Common mode filter temperature monitoringG453
Power cabling entry from bottomH350
38 Operation principle and hardware description
