DescriptionCode
Power cabling entry from topH351
Power cabling exit from bottomH352
Power cabling exit from topH353
Cable gland plates (3 mm steel, undrilled)H358
Common motor terminal cubicleH359
Cable gland plates (3 mm aluminum, undrilled)H364
Cable gland plates (6 mm brass, undrilled)H365
Common output terminals (for inverter modules mounted in the same cubicle)H366
Control cabling through floor of cabinetH367
Control cabling through roof of cabinetH368
Cable size 2 terminals for aluminum cables (frame R4i)H371
ACS-AP-W control panel (with Bluetooth)J400
Control panel mounting platformJ410
Common control panelJ412
ACS-AP-I control panel (without Bluetooth)J425
Panel bus (control of several units from one control panel)K450
FDNA-01 DeviceNet™ adapter moduleK451
FPBA-01 PROFIBUS DP® adapter moduleK454
FCAN-01 CANopen® adapter moduleK457
FSCA-01 RS-485 (Modbus/RTU) adapter moduleK458
FCNA-01 ControlNet™ adapter moduleK462
FECA-01 EtherCAT® adapter moduleK469
FEPL-02 Ethernet POWERLINK adapter moduleK470
FENA-11 Ethernet adapter module for EtherNet/IP™, Modbus TCP®and PROFINET IO® protocolsK473
FENA-21 Ethernet adapter module for EtherNet/IP™, Modbus TCP and PROFINET IO protocols,
2-port
K475
Ethernet switch for PC tool or control network (for max. 6 inverter units)K480
Ethernet switch with optical link for PC tool or control network (for max. 6 inverter units)K483
FEIP-21 Ethernet adapter module for EtherNet/IP™K490
FMBT-21 Ethernet adapter module for Modbus TCPK491
FPNO-21 Ethernet adapter module for PROFINET IOK492
Ethernet switch for PROFINETK493
Ethernet switch with optical link for PROFINETK494
Wired remote monitoringK500
Wireless remote monitoring with 4GK501
Wireless remote monitoring with BluetoothK502
Wireless remote monitoring with 4G and BluetoothK503
FIO-11 analog I/O extension moduleL500
FIO-01 digital I/O extension moduleL501
FEN-31 HTL incremental encoder interface moduleL502
FDCO-01 optical DDCS communication adapter moduleL503
Additional I/O terminal blockL504
Operation principle and hardware description 39
