Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)Analog inputs AI1 and AI2
(XAI:4 … XAI:7).
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])
Current/voltage input mode selection
by jumpers (ZCU) or switches (BCU)
Current input: -20…20 mA,
R
in
= 100 ohm
Voltage input: -10…10 V,
R
in
> 200 kohm
Differential inputs, common mode range ±30 V
Sampling interval per channel: 0.25 ms
Hardware filtering: 0.25 ms
Resolution: 11 bit + sign bit
Inaccuracy: 1% of full scale range
Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)Analog outputs AO1 and AO2 (XAO)
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])
0…20 mA,
R
load
< 500 ohm
Frequency range: 0…300 Hz (ZCU), 0…500 Hz (BCU)
Resolution: 11 bit + sign bit
Inaccuracy: 2% of full scale range
Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)XD2D connector
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])
Physical layer: RS-485
Transmission rate: 8 Mbit/s
Cable type: Shielded twisted-pair cable with a twisted pair for
data and a wire or another pair for signal ground (nominal
impedance 100 … 165 ohm, for example Belden 9842)
Maximum length of link: 50 m (164 ft)
Termination by jumper (ZCU) or switch (BCU)
Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)RS-485 connection (X485 [BCU])
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])
Physical layer: RS-485
Cable type: Shielded twisted-pair cable with a twisted pair for
data and a wire or another pair for signal ground (nominal
impedance 100 … 165 ohm, for example Belden 9842)
Maximum length of link: 50 m (164 ft)
Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)Safe torque off connection (XSTO)
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])
Input voltage range: -3…30 V DC
Logic levels: "0" < 5 V, "1" > 17 V.
Note: For the unit to start, both connections must be “1”. This
applies to all control units (including drive, inverter, supply, brake,
DC/DC converter etc. control units), but SIL/PL classified Safe
torque off functionality is only achieved through the XSTO con-
nector of the drive/inverter control unit.
Current consumption (continuous) per STO channel:
• Frames R1i…R4i: 56 mA
• Frame R5i: 21 mA
• Frames R6i…R7i: 41.5 mA
• Frames R6i…R7i with option +V992: 25 mA
• Frame R8i with BCU control unit: 66 mA per parallel inverter
module
EMC (immunity) according to IEC 61326-3-1 and IEC 61800-5-2
See also chapter The Safe torque off function (page 191).
Connector pitch 5 mm, wire size 0.5 … 2.5 mm
2
(22…12 AWG)Safe torque off output (XSTO OUT)
Maximum tightening torque 0.45 N·m (4 lbf·in[BCU])(BCU control units only)
To STO connector of inverter module.
Control units of the drive 93
