3.5.3 DC output busbar in a static DC system
A-
A+
A+ Positive DC output busbar A- Negative DC output busbar
3.5.4 Charge post CP500 Generation 3, outside
C
D
E
F
G
B
A
J
M
L
I
J
K
H
N
A EV charge cable
B RFID reader and the payment
terminal (option)
C Connector holder
D Touchscreen
E Door
F Top light
G Side LED strips
H Cable retraction system
I Enclosure
J Air inlet and outlet
K Type plate
L Antenna
M Hoisting points
N Plinth cover
Description
9AKK107992A6488-EN | 004 23
