ABB HP CP500 - PE Cable; AC Auxiliary Power Cables

Parameter Specification
Nominal voltage Uo (Phase to ground
nominal voltage) /U (Phase to phase
nominal voltage)
600/1000 Vac - 900/1500 Vdc
Minimum test voltage 6 kV
Ambient temperature range -40°C to 80°C (-40 °F to 176 °F)
Maximum cable temperature (on the sur-
face)
+90°C (+194 °F)
12.19.3 PE cable
Parameter
Specification
Cores 1 core, gn/ye
Cross section range 35 mm² (69 kcmil) (2 AWG)
Type Flexible, unshielded
Diameter 13 - 21 mm
Length Refer to the local rules.
Conductor Fine strand copper wire according to
VDE 0295 Cl. 5/ IEC 60228 Cl. 5
Insulation Special PVC that is serviceable for out-
door use, UV-protected, and oil resistant
Minimum nominal voltage Uo/U 600/1000 Vac
Minimum test voltage 4 kV
Ambient temperature range -40°C to 80°C (-40 °F to +176 °F)
Diameter of the PE conductor The same as the diameter of the phase
conductors
12.19.4 AC auxiliary power cables
Parameter
Specification
Number of cores 4
Cross section range 2.5 mm² (14 AWG)
Shielding No
Conductor Bare copper, fine wired, brunch stranded
according to VDE 0295 CI.5/IEC CI.5
Insulation Special PVC ( that is serviceable for out-
door use, UV-protected, and oil resistant
Minimum nominal voltage (Uo/U) 450/750 Vac
Minimum test voltage (AC) 4 kV
Ambient temperature range -40°C to +80°C (-40 °F to +176 °F)
Core identification According to IEC 60446
Strip length 11 mm (0.43 in)
Technical data
