5.5 Transport the EVSE on the site
5.5.1 General transport procedure
Preliminary requirements
1. The cabinets are unpacked. Refer to section 5.4.
Note: The charge post is delivered horizontally or vertically.
Caution: Do not tilt the power cabinet to the horizontal position. In the
horizontal position, the power cabinet breaks.
Procedure
1. Move the power cabinet to the installation location:
• Move the cabinet with a forklift truck. Refer to section 5.5.3.
• Hoist the cabinet. Refer to section 5.5.4.
2. Move the charge post to the installation location:
Situation
Procedure
Tilt the charge post to the vertical
position.
Refer to section 5.5.2.
Move the charge post with a forklift
truck.
Refer to section 5.5.3.
Hoist the charge post. Refer to section 5.5.4.
5.5.2 Tilt the charge post to the vertical position
Preliminary requirements
1. The charge post is in the
horizontal position.
2. The charge post is
unpacked. Refer to section
5.4.
• Hoisting equipment,
including cables, swivel eye
bolts or bolts with lifting
loops. Refer to section 12.3.
Warning:
Risk of pinching or crushing, the charge post is heavy
• Make sure that the hoisting equipment can lift the charge post safely.
Obey the safety instructions that apply to the hoisting equipment.
Take into account the dimensions, the mass and the center of gravity
of the charge post. Refer to chapter 12.
Inspection and transport
9AKK107992A6488-EN | 004 33
