ABB HP CP500 - DC Output Specifications; Logic Interfaces Specifications

Parameter Specification
Residual-current device In the range of 30 mA up to 300 mA
The power cabinet has an integrated
300 mA RCD (Type A) for the power sec-
tion.
Power consumption of the power cabi-
net
In standby status: ≤ 80 W
Power consumption of the charge post In standby status: ≤ 70 W
With the LEDs on: ≤ 145 W
Earthing system TN-C
TN-S
TN-CS
TT
Input AC power connection 400/230 VAC 3W + PE
Input voltage range 400 V AC +/- 10% (50 Hz or 60 Hz)
Nominal input current 277 A at 400 V AC
Maximum input current 308 A at 360 V AC
Power factor at full load > 0.97
Efficiency ≥ 94% at ≥ 20 % load
≥ 94% at ≥ 20 % load < 8% for > 90 kW output power
12.7 DC output specifications
Parameter
Specification
Output voltage range 150 - 920 V DC
Maximum output current 375 A DC (one power cabinet)
500 A DC (two power cabinets)
Output power 175 kW up to 40 °C (104 °F) - one power
cabinet
350 kW up to 40 °C (104 °F) - two power
cabinets
DC output current 500 A CCS (liquid cooled)
200 A CHAdeMO
12.8 Logic interfaces specifications
Parameter
Specification
RFID standard ISO/IEC 14443A/B, ISO/IEC 15393
RFID supported applications FeliCa
™
1, NFC, Mifare, Calypso
Network connection 4G, 3G, 2G, Ethernet
Technical data
76 9AKK107992A6488-EN | 004
