12.19.5 Interlock and DC guard cables
Parameter Specification
Number of cores 2 x 2 twisted pair (4 core)
Diameter (inside) 1.3 to 2.1 mm² (16 to 14 AWG)
Diameter (outside) 10 to 17 mm (0.39 to 0.67 in)
Shielding Tinned copper braid
Possible configuration: shielded 4 core
cable 2 x 2 pairs twisted or two separate
shielded dual core cables
Conductor Fine strand copper wire
Insulation PVC or other material that is serviceable
for outdoor use and UV-protected
Test voltage 1.5 kV
Strip length 11 mm (0.43 in)
12.19.6 CAN cables
Table 2: CAN cables between power cabinets
Parameter
Specification
Number of cores 1 x 2, twisted and shielded pair
Diameter 0.5 to 0.75 mm² (20 to 18 AWG)
Shielding Tinned copper braid
Conductor Fine strand copper wire
Nominal voltage 600/1000 V AC
Insulation PVC or other material that are serviceble
for outdoor use and are UV-protected
Minimum test 1.5 kV
Strip length 11 mm (0.43 in)
Table 3: Optical CAN cables between the power cabinet and the charge post
Parameter
Specification
Number of cores 2 fibre cores for installation
2 fibre cores as spare parts
Type OM3 (multimode) prefabricated
Connector B-FOC (ST
®
)
Diameter 13 to 21 mm (0.51 to 0.83 in)
Wave length 850 nm
Material PCF or fiberglass
Loop bend radius Minimum 64 mm (2.5 in)
Strip length 11 mm (0.43 in)
Technical data
9AKK107992A6488-EN | 004 99
