12.9 Current peaks during the start of a charge session (DC
output)
Parameter Specification
Duration of the current peaks 25 µs
Maximum current peak 60 A
12.10 Mass and center of gravity
12.10.1 Mass
Parameter
Specification
[kg] [lbs]
Mass of the power cabinet 1400 3086.5
Mass of the charge post 250 551.2
12.10.2 Center of gravity, power cabinet
X
Z
Y
A
A Center of gravity
Parameter Specification
[mm] [in]
X 587 23.1
Y 407 16.0
Z 1068 42.1
Technical data
9AKK107992A6488-EN | 004 77
