ABB HP CP500 - Charge Post (Prefab Concrete)

Parameter Specification
[mm] [in]
Y5 63 2.5
Y6 70 2.8
Y7 63 2.5
Y8 70 2.8
Cable conduit hole Maximum diameter
[mm] [in]
C1 160 6.3
C2 60 2.4
C3 60 2.4
C4 60 2.4
C5 125 4.9
C6 125 4.9
C7 125 4.9
Function for cable conduit holes
Cable conduit
hole
Cable conduit for these cables
Primary power cabinet Secondary power cabinet
C1 AC power AC power
C2 CAN, interlock and DC guard: to
the secondary power cabinet
CAN, interlock and DC guard: to
the primary power cabinet
C3 CAN, interlock and DC guard: to
the charge post
None
C4 AC auxiliary and PE: to the
charge post
None
C5 DC power: to the secondary
power cabinet
None
C6 DC power: to the charge post None
C7 DC power: to the charge post DC power: to the primary power
cabinet
12.17.3 Charge post (prefab concrete)
Foundation mass and loads
Parameter
Specification
Mass 1030 kg (2271 lb)
Nd 15.06 kN (3386 klbf)
Vd 5.25 kN (1180 klbf)
Md 8.36 kNm (74.1 klb-in)
Technical data
9AKK107992A6488-EN | 004 91
