12 Technical data
12.1 EVSE type
The EVSE type is a code, mentioned on the type plate. Refer to section 3.2.
The code is made out of 3 parts: T U V
Code part Description Value Meaning of the value
T Model HP Terra high power
U Part CP500 Charge post, 500 A DC
output
- Power cabinet
V EV charge cable con-
nection, in the case of
a charge post
C One CCS connection
CC Two CCS connections
CJ One CCS connection
and one CHAdeMO
connection
Peak output power, in
the case of a power
cabinet
175 Peak output power
[kW]
Examples
HP CP500 C:
• T = HP, Model = Terra high power
• U = CP500, Part = charge post 500 A DC output
• V = C, EV charge cable connection = one CCS connection
HP 175:
• T = HP, Model = Terra high power
• U = Part = power cabinet
• V = 175, peak output power is 175 kW
12.2 Parts included in the delivery
Parameter
Specification
Charge post Refer to the type plate. Refer to section
3.2.
Power cabinet Refer to the type plate. Refer to section
3.2.
Door keys Door keys for the power cabinet and the
charge post
Eye bolts to hoist the power cabinet M16, 63 mm (2.5 in)
Caps to replace the eye bolts after trans-
port of the power cabinet
To fit in the holes for the eye bolts
Technical data
72 9AKK107992A6488-EN | 004
