ABB HP CP500 - Charge Post: Exceptions for Bollards and Other Minor Fixed Obstacles

A Charge post
X1 Total required width for the charge
post
X2 Space required for the air inlet and
to open the side panel
X3 Space required at the sides to open
the door
X4 Total required width to open the
door
X5 Required width to open the side
panel
Y1 Space required for cable
replacement
Y2 Total required depth for the charge
post
Y3 Maximum sideway reach of the
wheelchair user
Y4 Space required to open the door
Y5 Required depth to open the side
panel
Parameter Specification
[mm] [in]
X1 1490 58.7
X2 450 17.7
X3 105 4.1
X4 800 31.5
X5 345 13.6
Y1 400 15.7
Y2 775 30.6
Y3 254 10
Y4 490 19.3
Y5 345 13.6
12.16.3 Charge post: exceptions for bollards and other minor fixed
obstacles
Note:
The bollards or minor fixed obstacles must have a maximum diameter of
150 mm (6 in), to permit service or maintenance operations.
