ABB HP CP500 - Electrical Installation Requirements (Europe)

Parameter Specification
EMC rating for the charge post The charge post complies with these
standards:
• EN 61000-6-3 : 2007 + A1: 2001 Emis-
sion standard for residential, com-
mercial and light-industrial environ-
ments (Class B)
• EN 61000-6-2 : 2005 Immunity for in-
dustrial environments
• EN 301489-1 V2.2.0 : 2017
The charge post also complies with the
less strict requirements in these stand-
ards:
• EN 61000-6-4: 2007 + A1: 2011 Emis-
sion standard for industrial environ-
ments (Class A)
• EN 61000-6-1 : 2007 Immunity for
residential, commercial and light-in-
dustrial environments
EMC rating for the power cabinet
The power cabinet complies with these
standards:
• EN 61000-6-4:2007 + A1 Emission
standard for industrial environments
(Class A)
• EN 61000-6-2: 2005 Immunity for in-
dustrial environments
If the power cabinet must comply with
Class B (residential), install an external
EMC filter: Schaffner type FN
3359HV-400-99. To order this part, give
the global ID: 6AGC079955. When this
external EMC filter is installed, the power
cabinet complies with this standard:
• EN 61000-6-3 : 2007 + A1 2011 Emis-
sion standard for residential, com-
mercial and light-industrial environ-
ments (Class B)
12.6 Electrical installation requirements (Europe)
Parameter
Specification
Circuit breaker Use a circuit breaker with the option for
an under voltage release device.
For example, refer to TMAX XT5 320 A
tuned according to type C or similar.
Surge protection device Type 2
Technical data
9AKK107992A6488-EN | 004 75
