ABB HP CP500 - Noise Level; Torque Specifications

Parameter Specification
IK10 (screen: IK08)
Altitude Maximum 2000 m (6562 ft) above the
sea level
12.13 Noise level
Noise level Specification [dB(A)]
Charge post, 500 A continuous up to
35 °C
≤ 60 at 1 m (39.4 in)
Maximum noise level of the charge post 68 at 1 m (39.4 in)
Power cabinet ≤ 65 at 1 m (39.4 in)
12.14 Torque specifications
Parameter
Specification
[Nm] [lb·in]
Power cabinet, fasteners to the founda-
tion
80 708
Power cabinet, nuts on the PE busbars 30 266
Power cabinet, nuts on the AC power
busbars
30 266
Power cabinet, screws in the terminal
blocks
1.3 11.5
Power cabinet, nuts on the DC power
busbars
30 266
Charge post, fasteners to the founda-
tion
80 708
Charge post, fasteners on the PE busbar Between 33 and 44 Between 292 and
389
Charge post, screws in the terminal
blocks
1.3 11.5
DC input cable to the connector 30 265.5
M5 fasteners (if not specified) 3.5 31.0
M6 fasteners (if not specified) 9 79.7
M8 fasteners (if not specified) 20 177
M10 fasteners (if not specified) 40 354
M12 fasteners (if not specified) 70 619.5
M16 fasteners (if not specified) 180 1593
Technical data
9AKK107992A6488-EN | 004 79
