12.15 Dimensions
12.15.1 Power cabinet
Parameter Specification
[mm] [in]
Width (X-dimension) 1170 46.1
Depth (Y-dimension) 770 30.3
Height (Z-dimension) 2030 30.3
Required cable slack for the AC input ca-
ble (measured from the top of the foun-
dation)
1000 39.4
Required cable slack for the PE cable
(measured from the top of the founda-
tion)
2000 78.7
Required cable slack for the DC output
cable (measured from the top of the
foundation)
2000 78.7
Required cable slack for the AC auxiliary
power cable (measured from the top of
the foundation)
2000 78.7
Required cable slack for the interlock
and DC guard, and CAN cables (meas-
ured from the top of the foundation)
2000 78.7
12.15.2 Charge post
Parameter
Specification
[mm] [in]
Width of the charge post (X-dimension) 590 23.2
Depth of the charge post (Y-dimension) 425 16.7
Height of the charge post (Z-dimension) 2463 97.0
Required cable slack for the PE wire
(measured from the top of the founda-
tion)
700 27.6
Required cable slack for the DC power
cables (measured from the top of the
foundation)
700 27.6
Required cable slack for the AC auxiliary
power cable (measured from the top of
the foundation)
1200 47.2
Required cable slack for the interlock
and DC guard cable (measured from the
top of the foundation)
1200 47.2
Technical data
80 9AKK107992A6488-EN | 004
