8 Electrical installation of the charge post
8.1 General procedure
Note: For a detailed overview of all electrical connections, refer to
section 12.20.
Preliminary requirements
1. The DC power cables are
installed in one of the
cable conduits. Refer to
section 12.18.
2. The other cables are
installed in the other cable
conduits. Refer to section
12.18.
•
Procedure
1. Open the door of the charge post. Refer to section 10.6.
2. Remove the protection plate. Refer to section 10.8.
3. Connect the cables to the charge post:
• PE wire. Refer to section 8.2
• DC power cable. Refer to section 8.3
• AC auxiliary power cable. Refer to section 8.4.
• Interlock and DC guard cable. Refer to section 8.5
• Optical CAN cable from the power cabinet. Refer to section 8.6
• Control cables for the tilt sensor (option). Refer to section 8.8.
• Ethernet cable. Refer to section 8.7.
4. Install the protection plate.
5. Close and lock the door of the charge post. Refer to section 10.9.
8.2 Connect the PE wire
Preliminary requirements
1. The door is open.
• Cable lug. Refer to section
12.4.
• Fasteners M11. Refer to
section 12.4.
• Wire stripper pliers
• Wire cutter
• Torque wrench
•
Electrical installation of the charge post
