Parameter Specification
[mm] [in]
Y0 371 14.6
Y1 150 5.9
Y2 26 1.0
Y3 248 9.8
Y4 70 2.8
Y5 100 3.9
Y6 200 7.9
Cable conduit hole Maximum diameter
[mm] [in]
C1 60 2.4
C2 60 2.4
C3 126 5.0
C4 126 5.0
Function for cable conduit holes
Cable conduit
hole
Cable conduit for these cables
C1 AC auxiliary and PE
C2 CAN, interlock and DC guard
C3 DC power
C4 DC power
Technical data
