Networks 105
The Services/firewall settings panel, Services settings panel and Mail servers (outgoing)
panel are described below.
Test SMTP settings
The Test SMTP settings dialog box contains the following components:
• From text box defines the email address of the sender.
• To text box defines the email address of the receiver.
• Subject text box defines the subject for the email message.
• Content text box defines the content for the email message.
• OK button closes this dialog box and sends an email to the receiver.
• Cancel button closes this dialog box.
Services/firewall settings panel
The Services/firewall settings panel has one service defined in every row. You can
enable or disable the service per each interface. You can also select the service to be
enabled for all interfaces.
The list has the following columns:
• Service column has every available service listed. After the service name there is an
icon. By clicking the icon a popup dialog box or a tooltip is opened providing more
details about the service.
• Interface column has multiple sub-columns. All interfaces are below this column.
• All column is always visible and enabled. The column has a check box which is
selected if the service has been enabled for all interfaces.
• When the All check box is selected all other check boxes in the interface column
are selected as well (in the same row). The All check box disables any firewall
limits and allows the service to be reached over any network connection.
• When the All check box is not selected all other check boxes in the interface
column are unselected as well (in the same row).
• Interface X column shows what services are selected for the current interface. It is
possible that there is no interface X column since the available interfaces depend on
